Description
| General Product Description* |
|
| Size: |
8″ diameter & 40″ length |
| Permeate Flow: |
6,500 gpd (24.6 m3 /d) |
| Salt Rejection: |
99.8% (99.7% minimum) |
| Configuration: |
Low Fouling Spiral Wound |
| Membrane Polymer: |
Composite Polyamide |
| |
|
| Product Use and Restrictions |
|
| Maximum Applied Pressure: |
1200 psig (8.27 MPa) |
| Maximum Chlorine Concentration: |
< 0.1 ppm |
| Maximum Operating Temperature: |
113 °F (45 °C) |
| pH Range, Continuous (Cleaning): |
2-11 (1-13) |
| Maximum Feedwater Turbidity: |
1.0 NTU |
| Maximum Feedwater SDI (15 mins): |
5.0 |
| Maximum Feed Flow: |
85 gpm (19.3 m3 /h) |
| Maximum Pressure Drop for Each Element: |
15 psi (0.10 MPa) |
| |
|
| *Please refer to standard testing conditions and details in the enclosed datasheet |
