Description
| General Product Description* | |
| Size: | 8″ diameter & 40″ length |
| Permeate Flow: | 7,700 gpd (29.1 m3 /d) |
| Salt Rejection: | 99.8% (99.7% minimum) |
| Configuration: | Low Fouling Spiral Wound |
| Membrane Polymer: | Composite Polyamide |
| Membrane Active Area: | 400 ft2 (37.2m2) |
| Feed Spacer: | 34 mil (0.86 mm) |
| Product Use and Restrictions | |
| Maximum Applied Pressure: | 1200 psig (8.27 MPa) |
| Maximum Chlorine Concentration: | < 0.1 ppm |
| Maximum Operating Temperature: | 113 °F (45 °C) |
| pH Range, Continuous (Cleaning): | 2-11 (1-13) |
| Maximum Feedwater Turbidity: | 1.0 NTU |
| Maximum Feedwater SDI (15 mins): | 5.0 |
| Maximum Feed Flow: | 85 gpm (19.3 m3 /h) |
| Maximum Pressure Drop for Each Element: | 15 psi (0.10 MPa) |
| *Please refer to standard testing conditions and details in the enclosed datasheet | |
| Weight | 16 kg |
